VTX Transmitters
5.8GHz / 1.6W VTX
SKU: VTX5G8-1600N
High-channel-count 5.8GHz FPV transmitter with 48 channels across 5362–5945MHz. Five selectable power levels up to 1.6W with MMCX connector and IRC-Tramp Smart Audio — versatile and competition-ready.
Frequency
5362–5945MHz
Channels
48CH
Max Power
1600mW
Power Levels
PIT/25/400/800/1600mW
Antenna
MMCX
Weight
15.8g
In StockMOQ 20 UnitsOEM Available48CH
24h ReplyQuote fast
Fast Sample3–5 days
Factory DirectNo markup
OEM ReadyMOQ 20
Specifications
Full Technical Parameters
Frequency Range5362–5945MHz
Channels48CH
Power LevelsPIT / 25 / 400 / 800 / 1600mW
Input Voltage7–36V DC (2–8S)
Output Voltage5V 1A
Antenna ConnectorMMCX
Smart AudioIRC-Tramp
Shell MaterialAluminum
Weight15.8g
MOQ20 units
FAQ
Common Questions
What is the minimum order quantity?
Can I get samples before placing a bulk order?
Do you support OEM / custom branding?
How long does shipping take?
What payment methods do you accept?
What warranty do your products come with?
Ready to order the 5.8GHz / 1.6W VTX?
Contact our sales team for factory-direct pricing, sample availability, and OEM customization. We respond within 24 hours.
